Why pre-clean metal ?
Aluminum coil or galvanized steel strip is cleaned by hot water and treated with chemical in order to form an ideal surface for coating with PE or PVDF. Another purpose for pre-clean metal is to enhance anti-corrosion feature of metal as well as strengthen bonding between metal sheet and coating layer.

Features
- Especially for metal surface degreasing.
- Easy to use on surface pretreatment.
- Suitable for chromate process.
Specification
The above specification is for reference only. Customers’ specification is available upon requests.
ALUMAX has the right to make any change.
Item & Type | AL-25 | AL-15 |
Line Speed | 25M/min | 15M/min |
* Strip Width | 1,000 ~ 1,600mm (max.) | 1,000 ~ 1,600mm (max.) |
Strip Thickness | 0.10 ~ 0.7 mm | 0.15 ~ 0.7 mm |
Coil O/D | 1,200 mm /1,300 mm | 1,200 mm /1,300 mm |
Coil I/D | Ø405 mm,Ø508 mm | Ø405 mm,Ø508 mm |
Coil Weight | 3,000 kgs /5,000 kgs | 3,000 kgs /5,000 kgs |
Line Space Dimension | 42,000L x 8,000W x 4,000H mm | 42,000L x 8,000W x 4,000H mm |
Line Weight | 40,000kgs (approx.) | 36,000kgs (approx.) |
Line Power | 113HP/180KW | 86HP/120KW |
Soft Water Quantity | 2,500 ~ 3,500L/hr | 1,800 ~ 2,500L/hr |
D.I Water Quantity | 1,000 ~ 1,500L/hr | 1,000 ~ 1,500L/hr |
Compressed Air Consumption | 0.8 ~ 1.5 M³/hr | 0.8 ~ 1.5 M³/hr |
* Strip Width on requests
The above specification is for reference only. Customers’ specification is available upon requests. ALUMAX has the right to make any change.
Flow Line
Coil
Spindle Clamp Uncoiler
Joiner
Brushing & Degreasing
Water Rinse
D.I. Water Rinse
Squeegee Rolls
Air Blow-off
Chemical Coating
Drying Oven
Cooling Unit
Bridle & Cooling Rolls
Shear
Spindle Clamp Recoiler
Aluminum Conversion
Coated Coil
Coated Coil
